    Hot Dipped Galvanized Steel Plate 30mm 3mm Cold Rolled Ppgl Electro

    Ask Lasest Price
    Certification : ISO 9001 ,CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000 Ton/Tons per Month
    Delivery Time : 7~10 working days
    Brand Name : JIANGSU ZHIJIA STEEL
    Price : Negotiation
    • Product Details
    • Company Profile

    Hot Dipped Galvanized Steel Plate 30mm 3mm Cold Rolled Ppgl Electro

    JIS SGCC/SGCD Hot-Dip Galvanized Steel Coil
    galvanized steel

    Galvanized Steel Sheet is defined as a carbon steel sheet coated with zinc on both sides. Galvanized Steel Coil Importer produce galvanized steel with two main processes: continuous hot dip galvanizing and electro-galvanizing.


    A zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.


    COATING

    TypeCoating mass(g/m2)Plate thickness(mm)Width(mm)
    Hot Dip Galvanized steelHot-dip galvanealed steel sheet and coil/strips30~1200.5~4.5580~1250
    Hot-dip galvanized steel sheet and coil/strips60~6000.23~6.0580~1250
    Hot-dip zinc-aluminum-magnesium-silicon alloy coated steel sheet and coil/strips60~2750.27~9.0580~1250
    Hot-dip aluminum coated steel sheet and coil/strips40~1600.3~2.5580~1250
    Electrogalvanized steelElectrolytic zinc coated steel sheet and coil/strip10~400.4~2.3580~1250
    Electrolytic zinc-nickkel coated steel sheet and coil/strip10~400.4~2.3580~1250

    GRADE

    DX51D+Z

    DX52D+Z

    DX53D+Z

    S280GD+Z

    S350GD+Z

    S550GD+Z

    DX51D+AZ

    DX52D+AZ

    DX53D+AZ

    S280GD+AZ

    S350GD+AZ

    S550GD+AZ

    DX51D+AZM

    DX52D+AZM

    DX53D+AZM

    S280GD+AZM

    S350GD+AZM

    S550GD+AZM

    SGHC

    SGH400

    SGCC

    SGCH

    SGCD

    SGC400
